2000 Circles L160F100 3.2v 100AH CALB Lithium Cells With Plastic Shell

2000 Circles L160F100 3.2v 100AH CALB Lithium Cells With Plastic Shell
2000 Circles L160F100 3.2v 100AH CALB Lithium Cells With Plastic Shell 2000 Circles L160F100 3.2v 100AH CALB Lithium Cells With Plastic Shell

Large Image :  2000 Circles L160F100 3.2v 100AH CALB Lithium Cells With Plastic Shell

Product Details:
Place of Origin: China
Brand Name: CALB
Certification: CE, UL,IEC62133,KC
Model Number: L160F100
Payment & Shipping Terms:
Minimum Order Quantity: 20
Packaging Details: 4~8PCS/CARTON,with bubble foam to fixed, with wooden shelf outside, or as your request.
Delivery Time: 1-100pcs 5 days;more than 100pcs to be negotiated
Payment Terms: T/T
Supply Ability: 100000 Piece/Pieces per Month Lithium iron phosphate cell
Detailed Product Description
Brand: CALB Model: L160F100
Grade: A Grade; Brand New Voltage: 3.2V
Capacity: >190AH Cycle Life: 2000 Circles
Shell Material: Plastic Internal Resistance(Ac. 1kHZ): 0.1~0.5mΩ
High Light:

100AH CALB Lithium Cells

,

L160F100 LiFePO4 Lithium Battery

,

L160F100 CALB Lithium Cells

2000 Circles L160F100 3.2v 100AH CALB Lithium Cells With Plastic Shell



CALB A Grade Brand New CA100 3.2v 100AH LiFePO4 Lithium Battery



Storage of CA100 Lithium iron phosphate cell:

CA100 Lithium iron phosphate cell should be stored (more than 1 month) in a clear, dry and ventilated room under ambient temperature of -20℃~25℃, and it should be kept away from caustic material, fire source and heat source. Do not invert battery during storage; and avoid mechanical shock and stress.

If the batteries kept for a long time, it should be charged and discharged at the standard model every six months. Store the battery in the state of 10%~30% SOC (voltage scope: 3.215V~3.305V).

Products Description
Model Name CALB A grade brand new CA100 3.2v 100AH LiFePO4 lithium battery backup power when block out in typhoone wildfire




General Specification
Nominal capacity 100Ah(true capacity is 110Ah-120Ah)
Nominal voltage 3.2V
Charge cut off voltage 3.65V
Discharge cut off voltage 2.5V
AC Impedance Resistance ≤0.5mΩ
Max Charge Current 1C(100Amper)
Max Discharge Current 1C for constant,2C for 3min,3C for 10S
Cycle Life ≥2000 cycles
Charging Temperature 0℃~55℃
Discharging Temperature -20℃~55℃
Dimension and Weight Dimension 160*49.5*116.5mm
Net Weight of cell 3.3±0.2 KG
Application Engine starting battery,Home appliances energy storage,Solar and wind power system,RV,Camping car,Yacht,boat,caravan,Golf cart etc.


Model: CA100;  Size: 142*67*215.5mm; Shell material: plastic

2000 Circles L160F100 3.2v 100AH CALB Lithium Cells With Plastic Shell 0

2000 Circles L160F100 3.2v 100AH CALB Lithium Cells With Plastic Shell 1

Note:

1.This item is 100Ah CALB item,100% Original Grade A Brand NEW.The true capacity is 110Ah-120Ah.

2.The price come with original Busbars and Bolts,One Battery will come with one pcs busbar and 2pcs bolt(e.g.,If buy 4pcs battery,we will send 4pcs cells with 4pcs busbars and 8pcs bolts)If need more please contact us online.Thank you!
3.The busbars size:88*22.2*2.5mm ; Screw size:M8
4.Test report available,and number of lable is consecutive.

In General,we will provide the electronic copy,if you need the paper work,pls contact sales to confirm.



Application

This model can be applied in communication base,motor thruster, RV power supply, mountain power generation, steet light, solor storage energy, audio equipment power supply and etc....

2000 Circles L160F100 3.2v 100AH CALB Lithium Cells With Plastic Shell 2



Product Features
* Genuine Grade A lithium battery cells, brand new
* Light weight and high performance
* Small internal resistance
* High energy density, low self-discharge
* Pollution free, long cycle life
* No memory effect
* Existing stock for short delivery time.
* OEM orders are available (battery pack, battery with spot welding ect.)

Safety instructions
1. Stop charging the battery if charging isn't completed within the specified time.
2. Stop using the battery if the battery becomes abnormally hot, order, discoloration, deformation, or
3. abnormal conditions is detected during use, charge, or storage.
4. Keep away from fire immediately when leakage or foul odors are detected. If liquid leaks onto your
skin or cloths, wash well with fresh water immediately.
5. If liquid leaking from the battery gets into your eyes, don't rub your eyes and wash them with clean
water and go to see a doctor immediately.
6. If the terminals of the battery become dirty, wipe with a dry cloth before using the battery.
7. The battery can be used within the following temperature ranges. Don't exceed these ranges.
8. The operating temperature is based on the cell surface temperature in hottest position in pack.
9. Charge temperature ranges : 0ºC ~ 50ºC
10. Discharge Temperature ranges : -20ºC ~ 75ºC
11. Store the battery at temperature below 45ºC
12. Cover terminals with proper insulating tape before disposal.
