LP18 Series 48v 200ah Lithium Solar Battery RS485 SPPC Case

LP18 Series 48v 200ah Lithium Solar Battery RS485 SPPC Case
LP18 Series 48v 200ah Lithium Solar Battery RS485 SPPC Case LP18 Series 48v 200ah Lithium Solar Battery RS485 SPPC Case

Large Image :  LP18 Series 48v 200ah Lithium Solar Battery RS485 SPPC Case

Product Details:
Place of Origin: China
Brand Name: Amazing Energy
Certification: CE ROHS
Model Number: 48V 200Ah
Payment & Shipping Terms:
Minimum Order Quantity: 10 packs
Packaging Details: Standard Export Carton
Delivery Time: 15 days
Payment Terms: T/T
Detailed Product Description
Battery Size: 51.2v 200Ah Nominal Capacity: 200Ah
Weight: 80KG Module Parallel: Up To 8 Packs
Peak Discharge Current:: 110 A (3s) Efficiency: >96%
High Light:

48v 200ah Lithium Solar Battery

,

LP18 Series Lithium Solar Battery

,

SPPC Case Solar Power Station

LP18 Series 48v 200ah Lithium Solar Battery Lithium Ion Batteries For Solar System



Our battery module consists of multiple cells connected in a series and/or a parallel, encased in a mechanical structure. The system is modular in design, allowing for it to be easily switched to a different capacity and power as per your demands. The unit can be wall mounted, floor mounted, and server rack mounted.





ELECTRICAL PERFORMANCE



Nominal Voltage

51.2 V

Nominal Capacity

200 Ah

Capacity @ 20A

150 min

Energy

10,240 Wh

Communication

CAN2.0/RS232/RS485

Resistance

≤100 mΩ @ 50% SOC

Efficiency

>96%

Module Parallel

Up to 8 packs

CHARGE PERFORMANCE



Recommended Charge Current

50A

Maximum Charge Current

100A

Recommended Charge Voltage

57.6V

BMS Charge Cut-Off Voltage

<58.4 V (3.65V/Cell)

Reconnect Voltage

>57.6 V (3.6V/Cell)

Balancing Voltage

<57.6 V (3.6V/Cell)

Maximum Batteries in Series

16 (*Consult us)

DISCHARGE PERFORMANCE



Maximum Continuous Discharge Current

100 A

Peak Discharge Current

120 A (3s)

BMS Discharge Cut-Off Current

300 A (300ms)

Balancing open voltage

55.2V (3.45V/Cell)

Recommended Low Voltage Disconnect

44 V (2.75V/Cell)

BMS Discharge Cut-Off Voltage

>32.0V (2s) (2.0V/Cell)

Reconnect Voltage

>40.0 V (2.5V/Cell)

Short Circuit Protection

250 ~ 500 μs

COMPLIANCE



Certifications

CE (battery) UN38.3 (battery)

UL1642 & IEC62133 (cells)

Shipping Classification

UN 3480, CLASS 9

MECHANICAL PERFORMANCE



Dimension (L x W x H)

482 x 410 x 133 mm

19.0 x 16.1 x 5.2″

Approx. Weight

11.4 lbs (25 kg)

Terminal Type

DIN POST

Terminal Torque

80 ~ 100 in-lbs (9 ~ 11 N-m)

Case Material

SPPC

Enclosure Protection

IP65

TEMPERATURE PERFORMANCE



Discharge Temperature

-4 ~ 131 ºF (-20 ~ 55 ºC)

Charge Temperature

-4 ~ 113 ºF (0 ~ 45 ºC)

Storage Temperature

23 ~ 95 ºF (-5 ~ 35 ºC)

BMS High Temperature Cut-Off

149 ºF (65 ºC)

Reconnect Temperature

131 ºF (55 ºC)

HEATING FOIL PERFORMANCE



Heating Temperature Range

-4 to 41 ºF (-20 to 5 ºC)

Heating Time

Approximately 1 hour @ 7.5 A

BMS Heating Foil Cut-Off

158 ºF (70 ºC)





Feature
Suitable applications include:
1.Solar Storage
2.Switching applications and more
3.Base transceiver station
4.Communication equipments
5.Central office
6.Telecommunication systems
7.Electronic cash registers
8.Microprocessor based office machine
9.UPS
