Custom Lifepo4 36v 100ah RV Lithium Battery Pack Waterproof IP65

Custom Lifepo4 36v 100ah RV Lithium Battery Pack Waterproof IP65
Custom Lifepo4 36v 100ah RV Lithium Battery Pack Waterproof IP65 Custom Lifepo4 36v 100ah RV Lithium Battery Pack Waterproof IP65 Custom Lifepo4 36v 100ah RV Lithium Battery Pack Waterproof IP65

Large Image :  Custom Lifepo4 36v 100ah RV Lithium Battery Pack Waterproof IP65

Product Details:
Place of Origin: China
Brand Name: Amazing Energy
Certification: CE/RoHS/UN38.3/MSDS
Model Number: AE36-100
Payment & Shipping Terms:
Minimum Order Quantity: 2pcs
Delivery Time: 5-8 days
Payment Terms: T/T
Detailed Product Description
Battery Type:: LiFePO4 Battery Rated Voltage: 36V
Rated Capacity: 100Ah Standard Charge Current: 30A
Charging Time: About 3.5h Waterproof: IP65
Working Temperature (CC/CV): Charge: 0~45℃; Discharge: -20~60℃ Casing Material For Single Cell: Nickel Plated Steel
Waterproof Dustproof Level: IP65 Porduct Name: Custom Lifepo4 36v 100ah RV Lithium Batter
High Light:

36v 100ah RV Lithium Battery

,

IP65 RV Lithium Battery

,

IP65 RV Lifepo4 Battery

Custom Lifepo4 36v 100ah RV Lithium Battery Pack Waterproof IP65



Marine Boat 36v 100ah Custom Lifepo4 RV Lithium Battery Pack



Features
1. Ideal drop-in replacement for lead-acid batteries
2. Longer cycle life than other lithium-ion batteries
3. Good high-temperature resistance.
4. No memory effect
5. Lighter weight compared with same size lead acid battery
6. IP65 waterproof ratings. Suitable for marine use.



Built in BMS overall protection
1.Over charged protection
2.Over discharged protection
3.Thermal protection
4.Over load protection
5.Over current protection



Specification-Marine Boat 36v 100ah Custom Lifepo4 RV Lithium Battery Pack



Normal performance
NO
Item
General Parameter
Remark
1
Model
IFR 3.2V 100Ah
Single
2
Casing material for single cell
Nickel plated steel

3
Standard capacity(0.2C5A)
100Ah or customized

4
Rated voltage
38.4V
(Work voltage:38.4V)
5
Max.Charge voltage
43.2V
(Single Ave. charge Voltage 3.6V)
6
Cut-off voltage
30V
(Single Ave. Discharge Voltage 2.5V)
8
Standard charge current
30A
0.3C
9
charging Time
About 3.5h

10
Max Continuous discharge current
100A
1.0C
11
Peak discharge current
200A
2.1C 10seconds
12
Battery dimension
520mm*267mm*218mm

13
(Approx.)Total weight(Approx.)
About 35.36kg

14
(Max, at 1000Hz.)Impedance(Max, at 1000Hz.)
≤ 20mΩ

15
(CC/CV)

Charge method (CC/CV)


Standard
0℃~45℃
discharge
-20℃~45℃
storage
-20℃~45℃


What can LiFePO4 battery be used for?

LiFePO4 batteries are commonly use for Marine,Recreational vehicles,Golf cart applications,CCTV,robotics,PV energy storage,etc...
YiChen LiFePO4 battery can be used for any system or application that would normally use Lead acid battery(AGM,GEL) in 12V,up to 48V. After removing the olf batteries,place LifePO4 batteries in the same way.

Application-Forklift Lithium Battery 24v 200ah Custom Lifepo4 RV Lithium Battery Pack
Custom Lifepo4 36v 100ah RV Lithium Battery Pack Waterproof IP65 0
Custom Lifepo4 36v 100ah RV Lithium Battery Pack Waterproof IP65 1

Questions and answers

Q1. Can I have a sample order?
A. Yes, we welcome sample order to test and check quality.
Q2. What about the lead time?
A. Samples need 4-10 days, mass production time needs 2-5weeks, it depends on order quantity.
Q3. Do you have any MOQ limit?
A. No, 1pc for sample checking is available, we have MOQ for mass production.
Q4. How do you ship the goods and how long does it take to arrive?
A. It usually takes 5-12 days to arrive. Airfreight and seafreight is also optional.
Q5. How to proceed with an order?
A.Firstly let us know your requirements or application.
Secondly, We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places a deposit for formal order.
Fourthly We arrange the production and then delivery
Q6. Is it OK to print my logo on the product?
A.Yes.OEM/ODM services offered
Q7.Is this product safe?
A:Passed the overcharge, over discharge, over temperature, short circuit, acupuncture and other safety tests, no fire, no explosion at any circumstance;
Q8.Which certificates do you have?
A:We have CE/ROHS/UN38.3/MSDS ...etc.
Q9.How about warranty?
A:5 year warranty.
Q10: How do you make our business long-term and good relationship?
A: 1. We keep good quality and competitive price to ensure our customers’ benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from,we’ll do our best to serve our customers to help them save time & money!
3.one selection,a lifelong conpanionship!
