Electric Car Phosphate 3.2v 105ah CATL Lifepo4 Cell Aluminum Shell

Electric Car Phosphate 3.2v 105ah CATL Lifepo4 Cell Aluminum Shell
Electric Car Phosphate 3.2v 105ah CATL Lifepo4 Cell Aluminum Shell Electric Car Phosphate 3.2v 105ah CATL Lifepo4 Cell Aluminum Shell Electric Car Phosphate 3.2v 105ah CATL Lifepo4 Cell Aluminum Shell Electric Car Phosphate 3.2v 105ah CATL Lifepo4 Cell Aluminum Shell

Large Image :  Electric Car Phosphate 3.2v 105ah CATL Lifepo4 Cell Aluminum Shell

Product Details:
Place of Origin: China
Brand Name: CATL
Certification: CE/RoHS/UN38.3/MSDS
Model Number: 3.2V 105Ah
Payment & Shipping Terms:
Minimum Order Quantity: 100 pcs
Price: USD 60-70
Packaging Details: UN box
Delivery Time: 1-100pcs 5 days；more than 100pcs to be negotiated
Payment Terms: T/T
Supply Ability: 1000 pcs per two weeks
Contact Now
Detailed Product Description
Style: Prismatic LiFePo4 Battery Typical Capacity: 105Ah
Typical Voltage: 3.2V Cyclelife: 4000 Times
Net Weight: 2.26KG Shell Material: Aluminum
Battery Size: 167mm*200mm*34mm Certificates: CE UN38.3 MSDS ROHS
High Light:

105ah CATL Lifepo4 Cell

,

105ah Lithium Iron Phosphate Cells

,

34mm CATL Lifepo4 Cell

Electric Car Phosphate 3.2v 105ah CATL Lifepo4 Cell Aluminum Shell


CATL Lifepo4 Battery Cell 3.2v 105ah Aluminum Shell Using For Golf Cart EV Electric Car
Products Description CATL BATTERY 3.2v 105ah lifepo4 battery size:



Items
Description
Dimensions (mm)
W
Width
34
T
Thickness
167
L
Length
200
Technical Parameters for CATL Lifepo4 Cell Battery



NO.
Items
Parameter
Remarks
1
Nominal Capacity
105Ah
Standard Discharge
2
Minimal Capacity
105Ah
Standard Discharge
3
Work Voltage
2.5~3.65V

4
Internal Resistance(Ac. 1kHz)
0.1~0.5mΩ
Fresh Cell,30%SOC
5
Charging Time
Standard Charge
~4h
Reference Value


Fast Charge
~1h

6
Recommended SOC Window
SOC :10%~90%

7
Operating Temperature
Charging Temperature
0~45°C
Refer to section 4.2


Discharging Temperature
-20~55°C
Refer to section 4.4
8
Weight
2.26kg





Battery Shipping Way for CATL Battery
1.  UPS / DHL / EMS / HK EMS / FEDEX / HK post / TNT and so on express(door to door)
2.  For Air Shipment, Please choose your favorite, shipping method according your detail requirement
3.  The shipping discount is different in different seasons and depend different weight, we will choose the cheapest and safest way according your detail quantities.
4.  Normally, it will take around 3-7days from China to destination country. Please note that some remote place will need 1-3 days more.
Product market

The rising global demand for solar,wind and other clean energy has seen the market grow exponentially over the last few years, with the trend predicted to continue. Due to the inherent limitations of renewable energy, the lithium battery energy storage industry develop rapidly.

Electric Car Phosphate 3.2v 105ah CATL Lifepo4 Cell Aluminum Shell 0

Long cycle life high quality CATL 3.2v 105ah Lithium Lifepo4 Battery for EV ESS golf cart

1. More than 3500 cycles under the designed working condition

2. Anti-explosion safety valve applied

3. Aluminum shell for better cooling

4. Ceramic membrane technology applied to enhance safety

5. Wild applications :UPS ,Solar Storage ,EV etc.application



Key Features for CATL Battery
♦  Longer Cycle Life : Offers up to 4000 times longer cycle life and 8 times longer float/calendar life than lead acid battery , helping to minimize replacement cost and reduce total cost of ownership.

♦ Lighter Weight : About 35% of the weight of a comparable lead acid battery . A " drop in" replacement for lead acid batteries.

♦ Higher Power : Delivers twice power of lead acid battery ,even high discharge rate, while maintaining high energy capacity.

♦ Wider Temperature Range : -20℃~60℃.

♦ Superior Safety: Lithium Iron Phosphate chemistry eliminates the risk of explosion or combustion due to high impact overcharging or short circuit situation.

♦ Environment friendly: Clean and Green energy poses no pollution on our environment.

Aplication for LFP Battery

Passenger and commercial plug-in hybrid electric vehicles (PHEVs).

· Passenger and commercial battery electric vehicles (BEVs).
· Mild and micro hybrid vehicles.
· Long-Duration (LD) grid energy storage systems.

1)  Electric vehicles and charging stations, tourist coaches, yachts, wind and solar energy storage power, traffic signals.

2)  Solar hybrid street lighting, UPS power supply, home storage.

3)  Coal, disaster relief emergency, weather radar, electricity, smart grid, communication base stations.

4)  Hospitals, finance, telecommunications , system critical backup power systems.





Electric Car Phosphate 3.2v 105ah CATL Lifepo4 Cell Aluminum Shell 1





Why Choose us
1.  Rich Experience: Professional Manufacturer in lithium-ion battery for many years
2.  Low MOQ: It can meet your business very well.
3.  OEM/ODM accepted: Please send us your requirements
4.  Good Service: We treat clients as friend with quickly action & respond
5.  High quality:100% tested in production, mass production are start after your confirmation received.
6.  Fast & Safe Delivery: We are in Shenzhen, with convenient transportation

Package & Shipping for CATL Battery

Electric Car Phosphate 3.2v 105ah CATL Lifepo4 Cell Aluminum Shell 2
